Durable 2 Axle LPG Trailer, LPG Tanker Trailer, LPG Tank Trailer
LPG gas is used as a fuel for many residential, commercial and
agricultural heat applications, including cooking. It is also
employed as a propellant, refrigerant and vehicle fuel. LPG gas –
Liquefied Petroleum Gas – describes flammable hydrocarbon gases
including propane, butane and mixtures of these gases. LPG Gas
comes from natural gas processing and oil refining.
I. Application
Use for carry liquid perto gas.
II. Feature
1. The accessories used at LPG semi-trailer and rigid tank are
selected with care to provide a safe, long-lasting and
user-friendly usage while considering air and environment
protection.
2. As LPG has a lighter density compare to many other liquid gases,
the capacity of LPG semi-trailer and rigid tank capacities are
comparatively higher.
3. The design pressure used for LPG Semi-Trailers and rigid tankers
17.5 to 23 Bar and the design temperature is between -20°C and
+70°C.
4. As its flammable nature, the safety becomes more important for
LPG. The cylindrical shape, like in other pressure vessels provides
a safety to store and transport liquids kept under pressure.
III. Quality guarantee
1. More than 30 years experiences in trailer and truck
industrial,exported to more than 30 countries in Africa,Southeast
Asia.
2 .Two years free warranty terms for the I beam,three to six month
free warranty terms for the Axles,suspension etc.
3. Spare parts support services.
4. Able to custom-built design as your requirment,ensure to meet
your local road regulation.
IV. Specification
| Style | 44Cbm 2 Axle LPG Tank Semi-Trailer |
| Feature | Carry Liquid Petro Gas |
| Dimension(L*W*H) | 11120*2500*4000 |
| Material | Q370R |
| Compartment | One |
| Capacity(kgs) | 44 CBM |
| Tare weight(kgs) | 14,000kgs |
| Kingpin | The world-famous JOST brand bolt-in/welded type 3.5”/2” |
| Landing gear | JOST brand two-speed manual operation 19” |
| Tire size | 12R22.5 |
| Rim size | 9.00*22.5 |
| Axle | Original BPW-12T |
| Leafs spring | Germany type with 12pcs of leafs spring/ Fuwa brand with 10 pcs of
leafs spring/ Airbag suspension |
| Brake system | One unit WABCO RE 4 relay valve; four units T30/30 spring brake
chamber; two units T30 spring brake chamber; two units reliable
local brand 45L air tank; two units reliable local brand standard
coppery air-connector. |
Emergency Valve (Liquid Phase) | Rego Brand, A3213R300, 2 Pcs |
Emergency Valve (Gas Phase) | Rego Brand, A3212R175, 1 Pc |
| PRV | Rego Brand, A 8436G , 2 Pcs |
| Vent Valve | Rego Brand, TSS3169 , 4 Pcs |
| Liquid Adaptor | Rego Brand, 5769K (3”, 3-1/4ACME),2 Pcs |
| Gas Adaptor | Rego Brand, 5767H (2”, 2-1/4ACME), 1 Pc |
| Angle Valve | Rego Brand, J415/ A2805C , 1 Pc |
| Pressure Gauge | Rego Brand, J542 /A 8400 , 1 Pc |
| Thermometer | Rego Brand, J700, 1 Pc |
| Liquid Level Gauge | Rego Brand, 6339M11/6342M11 , 1 Pc |
| Prime & Topcoat painting | S.A.2.5standard sandblasting ;Zinc-rich & Polyurethane painting |
| The LPG trailer can be designed and produced as your requirements |
IV. Detail Photo
